MEANWELL RSP320 12V IP20 POWER SUPPLY

The MEAN WELL RSP-320-12 is a low-profile (30mm) switched-mode power supply, specifically designed for industrial applications requiring high power in confined spaces. Its grid-type case design promotes heat dissipation, while its 1U (30mm) height allows for optimized integration into compact systems.

It accepts a universal input range of 88 to 264V AC at 47-63Hz, supplying a 12V DC output with a maximum current of 26.7A. The output voltage is adjustable via potentiometer between 10V and 13.2V DC, offering flexibility to adapt to the load requirements.

The power supply incorporates a power factor correction (PFC) >0.95, ensuring efficient performance and reducing distortions in the electrical grid. Its typical efficiency is 88%, guaranteeing optimal energy utilization.

It features reinforced 3000V AC isolation between input and output, and maintains a low noise and ripple level of 150mVp-p, providing a clean and stable power supply. The operating temperature range is from -30°C to +70°C, with drift curves specified in the datasheet.

Its dimensions of 215 x 115 x 30 mm make it an ideal solution for integration into low-profile electronic equipment. Furthermore, the RSP series includes a remote on/off function and a power indicator LED, facilitating system control and monitoring.

The RSP series is especially suited for industrial applications, telecommunications, automation, LED displays and high-performance electronic equipment.

The RSP-320-12 model includes a 3-year warranty and has international certifications CE, TUV, EAC, RCM, UKCA, CCC, BSMI and UL.
