MEANWELL ELG150 150W 12V IP65 POWER SUPPLY

The MEAN WELL ELG-150-12 power supply is a high-quality solution designed for powering LED strips, LED bulbs, and demanding, high-power lighting systems. Its weatherproof metal housing with IP67 protection makes it ideal for outdoor applications, industrial environments, and extreme environmental conditions.

It operates with an input range of 100 to 305V AC at 47-63Hz, supplying a 12V DC output with a maximum current of 10A, adjusting to the load demand. Its rated power is 120W, with a typical efficiency of 88%, guaranteeing excellent and stable energy performance.

The ELG-150-12 model offers reinforced 3750V AC isolation between input and output, maintaining a low noise level and a ripple of 150mVp-p. It incorporates a power factor correction (PFC) >0.95 at 230V AC at full load, and a no-load consumption of less than 0.5W, optimizing energy efficiency.

Its dimensions (219 x 63 x 35.5 mm) allow for easy installation, even in large-scale projects, and its wide operating temperature range (-40ºC to +90ºC Tc) makes it suitable for extreme conditions.

The MEAN WELL ELG series is specifically designed for public, architectural, and outdoor lighting applications, guaranteeing high efficiency and reliability. It also holds HL Class I Division 2 approval for explosive atmospheres in the USA.

This model includes a 5-year warranty and is certified by CE, BIS, CCC, RCM, KCC, ENEC, EAC, UKCA and UL.
