MEANWELL ELG200 200W 12V IP65 POWER SUPPLY

The MEAN WELL ELG-200-12 power supply is a high-performance solution designed to power LED strips, LED bulbs, and high-power lighting systems in demanding environments. Its weatherproof metal housing with IP67 protection makes it ideal for outdoor, industrial, and extreme environmental applications.

It operates with a wide input range of 100 to 305V AC at 47-63Hz, supplying a 12V DC output with a maximum current of 16A, automatically adapting to the load demand. Its rated power is 192W, with a typical efficiency of 90%, ensuring superior energy performance and stable operation.

The ELG-200-12 model features reinforced 3750V AC isolation between input and output, and maintains a low noise and ripple level of 150mVp-p. Furthermore, it incorporates a power factor correction (PFC) >0.95 at 230V AC under full load, and a no-load consumption of less than 0.5W, optimizing energy efficiency.

Its dimensions (244 x 71 x 37.5 mm) allow for its integration into professional lighting projects, even large-scale applications. Its extremely wide operating temperature range, from -40°C to +90°C (Tc), makes it suitable for the most demanding environments.

The MEAN WELL ELG series is specifically designed for public, architectural, and outdoor lighting applications, distinguished by its high efficiency, robustness, and reliability. It also holds HL Class I Division 2 certification for hazardous areas in the USA.

The model includes a 5-year warranty and is certified by CE, BIS, CCC, RCM, KCC, ENEC, EAC, UKCA and UL.
