MEANWELL HLG120 POWER SUPPLY 120W 24V IP65

The MEAN WELL HLG-120H-24 power supply is a high-efficiency and reliable LED driver, specifically designed to power LED strips, LED bulbs, and medium-power lighting systems in professional applications. Its weatherproof metal housing with IP67 protection ensures safe operation in demanding outdoor, indoor, and industrial environments.

It operates with an input range of 90 to 305V AC at 47-63Hz, supplying a 24V DC output with a maximum current of 5A, adapting to the load demand. Its rated power is 120W, with a typical efficiency of 93%, ensuring excellent energy performance and reliable operation.

The HLG-120H-24 model incorporates reinforced 3750V AC isolation between input and output, along with a power factor correction (PFC) >0.95 at 230V AC at full load, optimizing energy consumption and minimizing harmonic distortion in the network.

Designed according to Class I regulations, it requires grounding through its metal housing. Its operating temperature range is -40°C to +70°C (Tc), allowing it to operate in extreme environmental conditions. With dimensions of 220 x 68 x 38.8 mm, it integrates easily into professional lighting projects.

The MEAN WELL HLG series is distinguished by its high efficiency, reliability, and robustness, making it ideal for public, architectural, outdoor, and indoor lighting applications, as well as LED displays. This model complies with HL Class I Division 2 regulations for explosive atmospheres in the USA, ensuring its suitability for industrial environments.

It includes a 7-year warranty and is certified by CE, CCC, TUV, KCC, BIS, PSE, ENEC, EAC, RCM, UKCA and UL.
