MEANWELL 150W 12V IP65 5YEARS POWER SUPPLY

The MEAN WELL ELG-150-12 power supply is a high-quality solution designed to power LED strips, LED bulbs, and high-power, demanding lighting systems. Its IP67-rated, watertight metal housing makes it ideal for outdoor applications, industrial environments, and extreme environmental conditions.

It operates with an input range of 100 to 305V AC at 47-63Hz, providing a 12V DC output with a maximum current of 10A, adjusting to the load demand. Its rated power is 120W, with a typical efficiency of 88%, ensuring excellent and stable energy performance.

The ELG-150-12 model offers reinforced 3750V AC isolation between input and output, maintaining a low noise level and ripple of 150mVp-p. It incorporates a power factor correction (PFC) of >0.95 at 230V AC at full load, and a no-load power consumption of less than 0.5W, optimizing energy efficiency.

Its dimensions (219 x 63 x 35.5 mm) allow for easy installation, even in large-scale projects, and its wide operating temperature range (-40ºC to +90ºC Tc) makes it suitable for extreme conditions.

The MEAN WELL ELG series is specifically designed for public, architectural, and outdoor lighting applications, ensuring high efficiency and reliability. It also has HL Class I Division 2 approval for hazardous areas in the US.

This model includes a 5-year warranty and is certified by CE, BIS, CCC, RCM, KCC, ENEC, EAC, UKCA, and UL.
