MEANWELL 200W 12V IP65 5YEARS POWER SUPPLY

The MEAN WELL ELG-200-12 power supply is a high-performance solution designed to power LED strips, LED bulbs, and high-power lighting systems in demanding environments. Its IP67-rated, watertight metal housing makes it ideal for outdoor, industrial, and extreme environmental applications.

It operates with a wide input range of 100 to 305V AC at 47-63Hz, providing a 12V DC output with a maximum current of 16A, automatically adapting to load demand. Its rated power is 192W, with a typical efficiency of 90%, ensuring superior energy efficiency and stable operation.

The ELG-200-12 model features reinforced 3750V AC insulation between input and output, maintaining a low noise and ripple level of 150mVp-p. It also incorporates a power factor correction (PFC) of >0.95 at 230V AC at full load and a no-load power consumption of less than 0.5W, optimizing energy efficiency.

Its dimensions (244 x 71 x 37.5 mm) allow it to be integrated into professional lighting projects, even in large-scale applications. Its extremely wide operating temperature range, from -40°C to +90°C (Tc), makes it suitable for the most demanding environments.

The MEAN WELL ELG series is specifically designed for public, architectural, and outdoor lighting applications, featuring high efficiency, robustness, and reliability. It also has HL Class I Division 2 approval for hazardous areas in the US.

The model includes a 5-year warranty and is certified by CE, BIS, CCC, RCM, KCC, ENEC, EAC, UKCA and UL.
